PM Frequency Conversion Screw Air Compressor
Max air displacement: 36.17m3/min
Power: 200kw/275hp
Pressure: 8bar
Size: 3250*2500*2190mm
Weight: 6500kg
Lead Time: 10-20 working days
Video Description
Product Parameters
ZLS275HI+ 0.8MPa PM VSD AIR COMPRESSOR | ||||
1 | Displacement | m³/min | 0.65MPa | 41.8 |
0.7MPa | 38.9 | |||
0.8Mpa | 36.17 | |||
2 | Rated Power | kW/HP | 200/275 | |
3 | Ambient temperature | ℃ | ≤40℃ | |
4 | Cooling method | - | Air/water cooling | |
5 | Exhaust temperature | ℃ | ≤Ambient temperature+10 | |
6 | Air Outlet of the Oil content | PPm | ≤3 | |
7 | Dustiness | μm | ≤3 | |
8 | Noise Level | dB(A) | 80±2 | |
9 | Dimensions (L*W*H) | air cooling -mm | 3250*2500*2190 | |
10 | Weight | kg | 6500 | |
Product Details
1. On account of long-term research and a large number of field experiments, we get the technological base for optimising the matching and design of the air end. ZLS-Hi+ series products choose to optimise ratio and system design of the air end, and the air displacement can improve 10% compare the same power screw air compressor.
2. Compare with adopts old type IE4 motor air compressor, the air compressors change to IE4 permanent magnet VFD motor can save 4 thousand USD one year.
3. The IE4 permanent magnet motor meets International Electrotechnical Commission IEC60034-30:2008 standards; the customer could purchase with confidence.
4. In air compressor service life, almost 80% cost was electric cost, so to reduce your energy cost, Jaguar's ZLS-Hi+ series air compressor adopts variable frequency drive intelligent control technology, significantly reduce your energy consumption.
5. Fully sealed liquid-cooled motor: rare earth material NdFeB made IE4 permanent magnet motor. To protect the permanent magnet from contacting outside environment, it adopts unique liquid cooling technology, ensures that the motor will not demagnetisation.
Additional Products
Certifications
Jaguar air compressor won the ISO 9001:2015 Quality Management System certificate.
Our Company
Jaguar air compression has focused on research and development of air compressors for more than 30 years. The products are covering two-stage compression air compressor, Permanent Magnet screw air compressor, variable frequency air compressor, piston air compressor, etc. Moreover, Jaguar not only has its stable agents worldwide but also has a professional sales team. The products widely used in various industries such as the oil field, automobile, machinery, chemical, electric, steel, mining, textile, agricultural and environment protection. A domestic sales and service network has established to cover all around China, and products are exported to more than 40 countries and regions overseas.
Packing and shipping
1. Packing Details: Fumigated Wooden crate and carton.
2. Shipping method: by sea, by LCL/FCL or as requested
3. Delivery method: FOB, CIF, and EXW.
4. Delivery time: in 20-25 working days after receiving the deposit.
FAQ
Q1. What're the advantages of Jaguar's product?
A. Energy-saving, reliable and efficient
Q2. Are you a manufacturer or trading company?
A. We are a large professional air compressor manufacturer with more than 30years in air compressors industry.
Q3. What’s your delivery time?
A. Generally, it needs 25-30days.
Q4. How extended is your air compressor warranty?
A. We provide one year warranty for our air compressor.
Q5. How long could your air compressor be used?
A. Generally, more than ten years.
