Permanent Magnet Turbo Blower ZTB
Permanent Magnet Turbo Blower ZTB
Jaguar ZTB permanent magnet centrifugal turbo blower adopts aviation turbine technology, fitted with air foil bearings, 3D flow impellers and high-speed permanent magnet motors. Machined by five-axis equipment, the impeller runs stably. Without gearbox and lubrication system, it supplies fully oil-free clean air.
It saves up to 30% energy versus Roots blowers, with noise under 80dB and slight vibration, no extra sound insulation needed. Compact structure allows easy installation, equipped with intelligent touch screen and remote monitoring. Only air filter replacement is required for maintenance to lower costs.
Available from 22kW to 220kW, it applies to sewage aeration, desulfurization, fermentation, powder conveying and aquaculture. Energy-efficient, durable and low-maintenance, it is well-received globally to replace old high-power blowers.
Advantages
High Efficiency & Energy Saving
- Cuts energy consumption by 30% compared with conventional blowers
- Oil-free air bearings, no gearbox required
- Certified high-efficiency equipment
Full Intelligent Control
- Interactive intelligent touch screen with multiple operation modes
- Remote access to monitor operating parameters
Low Noise & Vibration-Free
- Operating noise below 80dB; air foil bearings enable vibration-free running
- No extra sound insulation needed for machine rooms, easy installation
Low Maintenance Cost
- Highly integrated all-in-one unit, compact and lightweight
- Only air filter cleaning and replacement required for routine upkeep
Comparison with Traditional Products
Traditional Blowers
Jaguar PM Turbo Blowers ZTB
Adopt gear and belt transmission, noisy and prone to wear.
Direct coaxial transmission with air foil bearings, no lubricating oil needed
Regular maintenance and replacement of consumable parts are required.
Zero wear and no extra maintenance costs.
Low efficiency during long-term operation; efficiency drops due to compression wear.
Ultra-high efficiency, saving 30% energy compared with traditional Roots blowers.
Bulky structure with slight vibration.
Compact structure, low vibration and noise below 80dB(A)
Core Technology
Air foil bearings
Jaguar air foil bearings run contact-free at high speed, fully oil-free.
Simple aerodynamic thrust/radial bearings, oil-free and maintenance-free.
Air lubrication, vibration-free and quiet.
Special coating reduces wear for long stable service.
Jaguar high-efficiency impellers
Self-developed 3D-flow impeller, 0.001mm precision via German Hermle 5-axis machining.
Anodized anti-corrosion surface for stable high-speed running.
Aviation AL7075 aluminum, light and low power loss.
120% overspeed tested for reliable safety.
Direct shaft coupling with 100% power transfer efficiency.
ultra-high efficiency permanent magnet motors
High-efficiency PMSM driver, efficiency ≥96%
Optimized design supports overspeed rotation
Precise speed control via frequency conversion
Compact motor structure
Powerful cooling for stable high-efficiency operation
Soft start avoids impact on power grid
innovative cooling system
Jaguar blower comes with integrated self-air cooling system. The shaft fan draws cool ambient air to cool the motor and exhaust heat. Different from water cooling needing circulating pumps, this air cooling works efficiently without extra power.
special high-speed frequency converter
Custom dedicated frequency converters are tailor-made for Jaguar centrifugal blowers with perfect matching, stable and reliable performance. Equipped with independent heat dissipation, the converter adapts to various working conditions.
intelligent control system
Premium PLC delivers stable precise control and anti-interference performance.
Optimized for high-speed blowers, supporting constant pressure/flow/speed modes.
RS485 communication enables easy operation & maintenance.
Application industry
To advocate energy conservation, emission reduction and sustainable development policies, Jaguar permanent magnet centrifugal blowers are widely adopted across various industrial sectors as major energy-consuming equipment. They feature high efficiency, low vibration, low noise, oil-free operation, and easy installation & maintenance.
Material & Gas Conveying
Applicable industries: cement, chemical, food industries Typical use: pneumatic conveying of industrial raw materials, dust and food
Wastewater Treatment
Function: aeration for sewage tanks to activate microbes for pollutant degradation Typical use: domestic & industrial wastewater treatment plants
Desulfurization & Denitrification
Function: treatment of industrial waste gas and flue gas Typical use: petrochemical plants, gas boilers, air pollution control
Biological Fermentation
Function: oxygen supply for fermentation bacteria Typical use: biopharmacy, vaccine & fertilizer production
Frequently Asked Questions
How much energy can Jaguar centrifugal blowers save compared with Roots blowers and screw blowers?
The Jaguar ZTB air-bearing centrifugal blower is equipped with a high-speed permanent magnet motor and three-dimensional impeller. It saves approximately 30% of total power consumption versus traditional Roots blowers, and delivers 15%–25% higher energy efficiency than standard screw blowers. Free of gearboxes and lubricant loss, its stepless variable frequency speed regulation matches real-time air demands for aeration and material conveying. The energy-saving advantage is more prominent under low-load conditions, bringing remarkable electricity cost reductions for long-term operation in wastewater treatment and material conveying.
Is daily maintenance complicated? Does regular lubricant refilling required?
+
-
The unit is nearly maintenance-free and requires no lubricant throughout its service life. The core air bearing operates suspended by an air film, with no oil circuits or gearboxes, eliminating oil replacement and filter maintenance. Only regular care for inlet filter media is needed: pre-filter media shall be blown clean weekly and replaced every half month, while high-efficiency filter cartridges are replaced monthly. Routine work also includes cleaning heat dissipation air ducts and checking operating parameters on the touchscreen, leading to far lower maintenance costs than conventional blowers.
Does the unit generate loud noise and heavy vibration during operation? Is sound insulation necessary for the blower room?
+
-
It supports stable round-the-clock continuous operation. Air bearings work without physical friction, so the impeller and motor suffer no abrasion loss, with a designed service life of over 15 years. The whole machine is fitted with multiple automatic protection systems against overheating, overpressure and overload. It automatically adjusts rotating speed amid load fluctuations, perfectly suited for year-round non-stop operation in municipal wastewater plants and factory production lines with an ultra-low failure rate.
Which industries are suitable for this Jaguar centrifugal blower?
+
-
It targets low-pressure, high-air-volume applications including aeration for municipal & industrial wastewater treatment, chemical desulfurization and denitrification, pneumatic conveying of powder materials, aquaculture oxygenation, and air supply for food fermentation. It provides 100% oil-free clean air that avoids contaminating water bodies and raw materials. Paired with intelligent frequency conversion, it automatically adjusts air volume based on tank water level and feeding volume, adapting to 24-hour continuous production scenarios.
